Description
FR10-32X is an adjustable, pressure compensated, bi-directional flow control valve.
Operation
The valve provides regulated flow in both directions from port 2 to 3 or 3 to 2 , port 1 should be blocked. Regulated flow increases from closed to fully open with clockwise rotation. The valve will maintain set up flow rate regardless of pressure variations at each of the ports.
Features
- Hardened seat for long life and low leakage.
- Excellent linearity and hysteresis.
- Industry-common cavity.
