TS90-31 is a pilot operated, spool type, proportional pressure reducing/relieving valve. The regulated pressure is proportional to the input electrical current. Protected by 50 x 50 mesh screen.
Without applied current, the TS90-31 allows bidirectional flow from port 2 to port 3, while blocking port 1. When the coil is energized, port 2 is connected to port 1, and pressure at port 2 is controlled proportional to the amount of current applied to the coil. If pressure at port 2 exceeds the setting induced by the coil, pressure is relieved to port 3.
- 12 and 24 volt coils standard.
- Optional waterproof E-Coils rated up to IP69K.
- Valve spool protected by a 50x50 mesh screen.
