Description
A load shuttle, screw-in, cartridge style, hydraulic check valve, for use in blocking circuits where a priority of flow/direction is given to a higher pressure circuit over a lower one.
Operation
The LS10-30 will allow flow from the higher pressure port 1 or 3 to port 2.
Features
- Rapid response to load direction changes. Industry-common cavity.
