Description
The MV06-20 is a screw-in, cartridge style, thumb or cam operated, two-way normally closed, poppet type, directional valve.
Operation
The valve blocks flow from port 2 to 1 until applied thumb or cam force is sufficient to overcome the spring bias plus load force.
Features
- Hardened seat and poppet for long life. Stainless steel cam button.
