Description
EC12-43 is a screw-in, cartridge style, priority on demand pressure compensator valve with dynamic load sense. It is intended to provide priority flow in required amount, while allowing excessive flow to be used for auxiliary functions.
Operation
With inlet flow at port 3, the EC12-43 will deliver required priority flow at port 4 regardless of load pressure. Excessive flow exits at port 2 and port 1 is the load sense port. All ports may be fully pressurized.
Features
- Priority-on-demand.
- Dynamic load sense.
- Hardened parts for long life.
- Quiet, modulated response.
- Industry-common cavity.
