Description
This valve is a direct-acting spool type 2 position, 4 way directional control. It is a screw in cartridge type for use with a general purpose hydraulic fluids.
NOTE: While 1 may be fully pressurized, it is not intended for use as the valve's inlet.
Features
- Continuous-duty rated coil.
- Hardened precision spool and cage for long life.
- Optional coil voltages and terminations.
- Efficient wet-armature construction.
- Cartridges are voltage interchangeable.
- All ports may be fully pressurized.
- Unitized, molded coil design.
- Manual override option.
- Optional waterproof E‑Coils rated up to IP69K.
- Industry-common cavity
- Compact size.
