Description
The SP08-22 is a solenoid operated, 2-way, normally closed, poppet-type, proportional, screw-in hydraulic cartridge valve, designed for low leakage blocking and load holding applications.
Operation
When de-energized, the SP08-22 acts as a check valve, allowing flow from 1 to 2, while blocking flow from 2 to 1. When energized, the poppet lifts to open the 2 to 1 flow path. Valve has a free reverse flow check to allow flow 1 to 2 when energized.
Features
- Continuous-duty rated coil.
- Hardened steel work surfaces.
- Optional waterproof E-Coils rated up to IP69K.
- Industry common cavity.
- Compact size.
