Description
CV10-28 is a screw-in, cartridge-style hydraulic check valve for use as a blocking or load-holding device. The cartridge incorporates a low flow thermal relief valve intended to prevent cylinder damage resulting from temperature-induced pressure intensification.
NOTE: The thermal relief feature is not intended for use in dynamic pressure limiting applications.
Operation
The CV10-28 allows flow from port 1 to port 2, while blocking oil flow in the opposite direction. If the pressure at port 2 exceeds the thermal relief setting, a small amount of oil will be allowed to pass from port 2 to port 1, preventing cylinder damage from pressure intensification.
Features
- Hardened seat for long life and low leakage.
- Industry-common cavity.
