Description
A solenoid operated, 3 way, direct acting, spool type, screw in hydraulic directional valve for high pressure circuits.
Operation
When de-energized, the SV58-30 allows flow from port 2 to port 1. While blocking flow at port 3. When energized, the cartridges spool shifts to open from port 3 to port 2 , while blocking flow out port 1, while port 1 may be fully pressurized, it is not intended to be used as the inlet.
