Description
The frr10-40 is a screw in, cartridge type, combination valve including a fixed orifice, pressure compensated, priority type flow regulator and a pressure relief valve.
Operation
With inlet at port 1 and ports 4 and 2 connected to tank, the valve maintains a constant flow rate from port 3 regardless of pressure variations at port 3.
Features
- Compact size.
- Two valve functions in one, industry-common cavity.
- Efficient - FR portion is vented.
- Quiet, modulated response.
- Hardened parts for long life.
